AIRTEC 484 SMERIGLIATRICE FRESATRICE PINZA Ø 3-6 MM
  • AIRTEC 484 SMERIGLIATRICE FRESATRICE PINZA Ø 3-6 MM
  • Dinamitek 1

484 GRINDER MILLING COLLET Ø 3-6 MM AIRTEC

Pneumatic straight grinder with 6 mm collet and 3 mm cutter adapter Airtec Model 484 (Code 13200000).

The Airtec Mod. 484 grinder-miller is a compact, easy-to-handle and ultra-light compressed air tool designed by Airtec Srl to carry out high-precision grinding, deburring, milling and finishing operations with rotary tools and milling cutters.

  • Ø 6 mm blade holder collet with Ø 3 mm adapter as standard: equipped with 6 mm main collet and supplied with adapter for the immediate use of cutters with 3 mm shank.
  • 0.20 kW 20,000 rpm pneumatic motor: develops a continuous power of 0.20 kW and a no-load rotation speed of 20,000 rpm at 6.2 bar pressure.
  • Ergonomic and Ultralight Design (only 0.62 kg): compact body just 170 mm long to ensure maximum guiding precision during detailed work.
  • Low Vibration Level (< 2.5 m/s²): optimal mechanical balance to minimize stress on the operator's hand.
Shipping cost: €15.00 for
€91.20
76,13 € Save €15.07
Tax included

62,40 € Tax excluded

Quantity
Available product, order it now.

Technical Features and Performance of the Airtec Mod. 484 Grinder

The Airtec Mod. 484 compressed air grinder/miller (Code 13200000) is the ideal workshop tool for model makers, mold makers, carpenters, and craftsmen who require high speed and accuracy when deburring weld seams, finishing slots, and grinding complex seats. Its compact 170 mm design and low weight of 0.62 kg allow for pinpoint control of movement.

The tool operates at a recommended operating pressure of 6.2 bar via a 1/4" BSPT threaded connection and a 10 mm internal diameter hose, recording an average air consumption of 12.5 litres per second. The dual predisposition for accessories with 3 mm and 6 mm shanks ensures maximum operational versatility when using abrasive grinders and carbide cutters (HM).

Detailed Technical Data Sheet

  • Product Code / SKU: Cod. 13200000 / Mod. 484
  • Manufacturer / Brand: Airtec Srl
  • Product Type: Pneumatic Straight Grinder / Milling Machine
  • Collet Size: Ø 6 mm (including adapter for Ø 3 mm shanks)
  • Power Output: 0.20 kW
  • No-load speed: 20,000 rpm
  • Recommended Air Pressure: 6.2 bar
  • Average Air Consumption: 12.5 l/sec
  • Air Connection: 1/4" BSPT
  • Recommended Air Hose Internal Diameter: 10 mm
  • Ergonomic Features:
    • Compact straight structure with high maneuverability
    • Adapter for cutters and grinders Ø 3 mm included
  • Noise and Vibration Levels:
    • Sound pressure: 92.3 ± 3 dB(A)
    • Sound power: 95.3 ± 3 dB(A)
    • Vibration level: < 2.5 m/s²
  • Dimensions and Weight:
    • Total length: 170 mm
    • Net weight: 0.62 kg
Wide selection of high-performance professional pneumatic grinders

AIRTEC: PROFESSIONAL PNEUMATIC TOOLS FOR WORKSHOPS AND INDUSTRY

Airtec is a brand specialising in professional pneumatic tools, designed to guarantee high performance, operational continuity and maximum reliability in mechanical, industrial and maintenance work. Airtec solutions are designed for intensive use, with robust, ergonomic tools suited to demanding working conditions.

The range mainly comprises professional pneumatic grinders, available in various configurations for cutting, deburring, finishing and material removal. Each tool stands out for its power, precision, smooth rotation, low vibration and long service life.

Airtec is recognised for reliability, build quality and consistent performance, with tools designed to ensure fast, safe and high-quality work. Professionals choose Airtec for efficiency, robustness and precision, essential elements in everyday pneumatic operations.



484
