816917 SUPERMIG 505I XD PULSE MULTIPROCESS INVERTER WELDER 230V 400V TELWIN

The pinnacle of industrial intelligence meets pulsed power! The Telwin Supermig 505i XD Pulse (code 816917) is the 400A multi-process inverter welder designed for Industry 4.0. Thanks to the WAVE OS operating system and Pulsed/POP (Pulse on Pulse) technology, you will have total control of the arc, ensuring flawless aesthetic and structural results on any material, from steel to aluminum. Robust, compliant with the XD (eXtra Duty) version for extreme duty cycles and equipped with ATC technology for thin sheet metal, it is the ultimate tool for those who demand maximum customization and work traceability via USB.

Shipping cost: Free for
3089,61 €
Tax included

2.532,47 € Tax excluded

Quantity
Available product, order it now.

Telwin Supermig 505i XD Pulse: Multiprocess Excellence with WAVE OS System

The Supermig 505i XD Pulse is not just a welder, but an advanced welding system that operates in MIG-MAG, FLUX, BRAZING, MMA and TIG DC-Lift modes. It is designed to support continuous and heavy-duty work in industrial environments, ensuring flexibility and easy transport despite its great power.

WAVE OS System and Pulsed Welding

  • WAVE OS (Welding Advanced Visual Environment): An intelligent interface with EASY (for quick setup) and EXPERT (for maximum customization) modes. Allows you to track and analyze welding data via USB for quality control.
  • Pulsed and POP (Pulse on Pulse): Drastically reduces heat input and spatter, ideal for aluminum and positional machining, ensuring clean beads and high penetration.
  • ATC (Advanced Thermal Control) Technology: Ideal for welding on ultra-thin surfaces (0.5-0.8 mm), where arc control prevents deformations and holes in the material.

Industrial Reliability and Safety

The machine is built to the XD (eXtra Duty) standard to withstand extended work cycles. The dedicated tunnel ventilation system protects the electronics from dust and conductive dirt, extending the generator's operating life. It also includes the VRD device for operator safety in humid environments.

Main Technical Specifications

  • Product code: 816917.
  • Power supply: Three-phase 230 / 400 V.
  • Maximum current (EN 60974-1): 400 @ 60% A (at 400V).
  • Current regulation range: 20 - 400 A (at 400V.
  • Display: High resolution color TFT graphic.
  • Dimensions and Weight: 54.6 x 27.4 x 50 cm | 32 kg.
  • Degree of protection: IP23.

Equipment Included

The product comes complete with:

  • Ground cable and clamp (70mm² - 3m).
  • Flashlight hook and holder.
A leading Italian company in welding, plasma cutting and charging and starting systems. Professional solutions for workshops, body shops, construction sites and industry, featuring reliable, high-performance technologies.

TELWIN: ITALIAN WELDING TECHNOLOGY SINCE 1963

Telwin is a long-established Italian brand, specialising in inverter welders, plasma cutters and charging/starting systems for the professional sector. Its solutions are designed for high-intensity environments such as mechanical workshops, automotive workshops, body shops, construction sites and industrial maintenance, where precision and operational continuity are essential.

The range includes MIG/MAG, TIG, MMA, high-precision plasma cutting, smart battery chargers, digital starters and multifunction stations for body shops.

The various product lines are distinguished by power, duty cycle, inverter technology, portability and electronic protection systems, making them suitable for both fixed workstations and mobile applications.

Telwin is recognised for structural reliability, arc stability, certified safety and continuous innovation, supported by in-house research and technological development.

Professionals choose Telwin for consistent performance, weld bead quality, reduced processing times and operational continuity even under demanding conditions.
