X472425 ZECA DATAFLUX SERIES 47 CABLE REEL
The mint Dataflux 472425 cable reel, from the 47 Series, is designed for the transmission of a very high number of signals in industrial contexts.
With a TPE cable (24x0.25) and an IP42 protection rating, it ensures tidy and reliable cable management, contributing to a safer and more efficient working environment.
mint 472425 Dataflux Series 47 Cable Reel
The Dataflux 472425 cable reel is part of mint's 47 Series and was developed for signal transmission in applications requiring large quantities of conductors for complex operations. The cable reel is designed to contribute to a more organized and safe work environment, preventing clutter and potential cable damage.
Main Technical Features:
- Series: Dataflux Series 47.
- Cable Composition: Cable with 24 conductors of 0.25 mm² each.
- Cable Length: 6 meters, with 1 meter of input cable.
- Cable Type: Made of TPE (thermoplastic elastomer). The cable is sheathed with a highly flexible PUR/TPE compound, resistant to abrasion, oils, and coolants. It is free of silicone, halogens (compliant with EN 50267-2-1), and lead (compliant with 2011/65/EU ROHS-II). The conductors are bundled and stranded with short pitches, optimized for excellent torsional strength, ideal for dynamic installations.
- Degree of Protection (IP): IP42 , offering protection against the entry of solid objects greater than 1 mm and against falling drops of water with a maximum inclination of 15°.
- Dataflux Collector: Includes a special collector with 6, 12, or 24 tracks, a maximum current rating of 2A, and a maximum voltage of 48V. Gold alloy rings and brushes ensure extremely high reliability and durability with very low friction. The dielectric strength is 500 VAC at 60 Hz, the insulation resistance is >1000 MΩ/500 VDC, and the noise is less than 100 mΩ. Bandwidth of 1 GHz.
- Atex: This model is not Atex.
- Cable Diameter: 10.5mm.
Advantages and Applications:
The 472425 is ideal for use in robotics, industrial automation, measurement and inspection systems where the management of numerous signals is required with the guarantee of a stable connection and good flexibility of use.
