ZECA AL41/315/B AVVOLGICAVO AUTOMATICO IN ALLUMINIO 15M 3G1.5 NERO Dinamitek 1
  • ZECA AL41/315/B AVVOLGICAVO AUTOMATICO IN ALLUMINIO 15M 3G1.5 NERO Dinamitek 1
  • ZECA AL41/315/B AVVOLGICAVO AUTOMATICO IN ALLUMINIO 15M 3G1.5 NERO Dinamitek 2
  • ZECA AL41/315/B AVVOLGICAVO AUTOMATICO IN ALLUMINIO 15M 3G1.5 NERO Dinamitek 3

AL41/315/B 15M 3G1.5 BLACK AUTOMATIC ALUMINUM CABLE REEL ZECA

Automatic spring-loaded cable reel extension with painted die-cast aluminium body, 15 m of 3G1.5 mm² PVC cable and free output cable Zeca AL41 Black Series Art. AL41/315/B.

The Zeca extension cable reel, item AL41/315/B (part of the prestigious AL41 Black Series), is a high-performance power supply featuring a black epoxy powder-coated die-cast aluminum housing. Designed for the most demanding industrial environments and workshops, it guarantees superior mechanical resistance and durability compared to traditional plastic reels.

  • Rugged Black Die-Cast Aluminum Construction: Ultra-resistant epoxy powder-coated aluminum case from the elegant "AL41 Black" line.
  • 15 Meters of PVC Cable (3G1.5 mm²): equipped with 15 meters of three-wire cable with a cross-section of 1.5 mm² and a maximum insulation voltage of up to 500V.
  • Free Output Cable (Wired Version): supplied without sockets and plugs to allow direct connection to fixed equipment or the installation of specific connectors.
  • Electrical capacity up to 1.8 kW: guarantees a power of 1,200 W with the cable wound and 1,800 W with the cable fully unwound at 20°C.
Shipping cost: Free for
169,23 €
Tax included

169,23 € Tax excluded

Quantity
Available product, order it now.

Technical Features and Performance of the Zeca Cable Reel Extension Art. AL41/315/B

The Zeca automatic cable reel, Art. AL41/315/B, combines the structural solidity of die-cast aluminum with the precision of the patented Zeca automatic spring rewinding system. Designed to withstand impacts, shocks, and the harsh daily use of production departments, it is equipped with an adjustable mounting bracket for wall or ceiling mounting.

Electrical conduction is handled by a collector with sliding brushes and a double ground contact. The rack-and-pinion locking mechanism holds the cable at the desired length every 50 cm and can be disengaged if continuous cable tension is preferred.

Note on conformity: Since this is a version supplied with a free cable (without factory-wired sockets or plugs), the CE marking and the related certificate of conformity of the system are the responsibility of the installer or qualified technician who takes care of the wiring and final commissioning.

Detailed Technical Data Sheet

  • Product Code / Article: Art. AL41/315/B
  • Manufacturer / Brand: Zeca SpA
  • Series: AL41 Black Series / Aluminum Extensions
  • Product Type: Automatic spring-loaded cable reel extension with aluminum body
  • Case Material: Die-cast aluminum painted with epoxy powder
  • Body Color: Black (Line Black)
  • Total Cable Length: 15 meters
  • Number of Conductors and Cable Section: 3 G x 1.5 mm²
  • Cable Type: PVC
  • Sockets / Plugs: None / Free output cable
  • Nominal and Maximum Voltage: 230 V (V max 500 V)
  • Electrical Rating and Power (@20°C):
    • Wrapped cable: 1,200 W (1.2 kW)
    • Unwound cable: 1,800 W (1.8 kW)
  • Thermal Protector Circuit Breaker: Absent (NO)
  • Construction and Functional Specifications:
    • Rack cable stop device every 50 cm (disengageable)
    • Double earth contact
    • Adjustable wall or ceiling bracket
  • Operating Ambient Temperature: -5 °C / +50 °C
  • Packaging dimensions: 360 x 310 x 185 mm
Leading Italian company in the automotive and industrial sectors, specialising in cable reels and professional equipment for mechanical workshops

ZECA: ITALIAN EXCELLENCE FOR PROFESSIONALS SINCE 1929

Zeca is a historic brand specializing in cable reels, hose reels, professional lamps and work organization tools.

Its solutions are designed for high-intensity environments such as workshops, automotive, construction, agriculture, and industry.

The product range includes electric and signal transmission cable reels, hose reels for air and fluids, rechargeable and under-hood lamps, balancers, and garage tools.

The different lines differ in terms of materials, capacity, cable length and degree of protection, so that they can be adapted to fixed or mobile locations.

Zeca is well-known for its products' durability, certified safety (ISO 9001, 14001, 45001) and continuous innovation, backed by patents and rigorous internal testing.

Professionals choose Zeca for mechanical reliability and practicality even in harsh conditions.
