• 1169F T27 DISCO LAMELLARE PIATTO 115 mm X 22.23 mm 3M™ CUBITRON™ 3 VARIE GRANE cf 100 pz Dinamitek 2
  • 1169F T27 DISCO LAMELLARE PIATTO 115 mm X 22.23 mm 3M™ CUBITRON™ 3 VARIE GRANE cf 100 pz Dinamitek 3

115 MM X 22.23 MM 3M™ CUBITRON™ 3 VARIOUS GRITS (CF 100 PCS) 1169F T27 FLAT FLAP DISC

The Evolution of Cutting: 3M™ Cubitron™ 3 1169F Redefines the Standard for Flap Discs

The 3M™ Cubitron™ 3 Flap Disc 1169F represents the pinnacle of abrasive technology for metalworking. Featuring newly re-engineered Precision Shaped Grain (PSG) technology with curved sides, this disc cuts faster and lasts significantly longer than traditional ceramic, aluminum oxide, or aluminum zirconium flap discs. Designed for versatility and convenience, the 1169F delivers consistent cutting speed throughout its life thanks to its flakes that continually fragment, exposing new cutting mineral. Ideal for use on carbon steel, stainless steel , and heat-sensitive alloys, it often allows grinding and finishing to be done in a single pass, reducing operating time and costs.

Choosing Dinamitek as an official 3M partner means investing in cutting-edge innovation, with the guarantee of original products ready to maximize your workshop's productivity. For large orders, contact info@dinamitek.com

Shipping cost: Free for
511,17 €
Tax included

418,99 € Tax excluded

Choose
Quantity
Available product, order it now.

3M™ Cubitron™ Flap Disc 3 1169F – Ø 115 mm x 22.23 mm

The 3M™ Cubitron™ 3 Disc 1169F is a versatile, ultra-high-performance Type 27 (flat) abrasive designed for medium- to high-pressure applications. Featuring a durable Y-weight polyester backing, this disc is built to handle the toughest everyday jobs while ensuring conformability and ease of use.

Cubitron™ 3 Technological Innovation

  • Reengineered Precision Shaped Grain: The new patented curved-edge ceramic grain structure allows the mineral to fracture into even sharper points. This prevents the "plowing" effect of traditional abrasives, cutting through metal cleanly and quickly.
  • Unmatched Productivity: The 1169F removes up to 49% more material than the Cubitron™ II 969F and up to 66% more than the 769F.
  • Grit Versatility: Available in 40+, 60+ and 80+ grits to cover every need from heavy grinding to surface finishing.
  • Long Life: Designed to last up to 10 years (3650 days) from date of manufacture, maintaining consistent performance over time.

Main Applications

The 1169F flap disc covers a wide range of applications in the aerospace, railway, marine and heavy industry sectors:

  • Grinding and grinding of welds;
  • Chamfering and deburring of edges and contours;
  • Preparation of surfaces for painting;
  • Calamine removal and masking.

Technical Specifications for Variant

  • Overall Diameter: 115 mm.
  • Center Hole Diameter: 22.23 mm.
  • Disc Type: Type 27 (Platter).
  • Abrasive Material: Precision Shaped Ceramic.
  • Backing: Y-Weight Polyester.
  • Max Speed: Optimized for standard angle grinders.

Variant Identification Codes:

  • Grit 40+: 3M ID 7100379604 | UPC 00068060117410.
  • Grit 60+: 3M ID 7100379795 | UPC 00068060117663.
  • Grit 80+: 3M ID 7100379600 | UPC 00068060117595.

Technical Tip: In many applications, the 1169F disc eliminates intermediate steps by producing a finer finish than a fibre disc of the same grit, allowing you to grind and finish with a single tool.
Superior performance with 3M™ Cubitron™ 3: +56% material removed and faster cutting on stainless and steel. The new era of PSG abrasives.

3M™ Cubitron™ 3 is the direct evolution of Precision Shaped Grain (PSG) technology, redesigned to ensure an even more controlled fracture of the abrasive grain.

It is designed for high-intensity sectors such as heavy steelwork, stainless steel, shipbuilding, metalworking and robotic grinding.

The range includes fibre discs, grinding discs, cut-off discs and solutions for aggressive stock removal on alloy and high-strength steels.

Compared to Cubitron™ II, the Cubitron™ 3 line offers faster cutting, less heat build-up and up to 56% more material removed.

Choose it for consistent productivity, reduced vibration and significantly longer abrasive life.

Avoid excessive pressure: the grain works best with steady feed, exploiting the self-sharpening PSG geometry.

Technical tip: always use original 3M backing pads to keep the optimal working angle and maximise disc life.



7100379604

Specific References

EAN13
0068060117422
