816057 TECHNOMIG 225 DUAL SYNERGIC 230VMIG-MAG 1-PH WELDING MACHINE TELWIN

TECHNOMIG 225 DUAL SYNERGIC 230V
code 816057
Microprocessor-controlled MIG-MAG/FLUX/BRAZING/MMA/TIG DC-Lift multi-process inverter welding machine.
The flexibility of use and the different welded materials (steel, stainless steel, aluminium) or brazed (galvanised sheets) confirm Technomig Dual Synergic as an excellent solution in a wide variety of fields of application, from maintenance to installation to bodywork interventions.
The rapid SYNERGIC adjustment of the welding parameters, thanks to the ONE TOUCH LCD SYNERGY technology, makes the product very simple to use.
Intelligent and automatic control of the arc, instant by instant, will maintain high welding performance in all working conditions, with different materials and/or gases.
It is also possible to manually adjust the arc length: this adjustment will allow you to modify the shape of the welding bead based on the welder's style.
The ONE TOUCH LCD graphic display allows for better reading of all welding parameters.
ATC technology, Made in Telwin, allows you to easily obtain excellent welds on thin surfaces thanks to advanced arc control.
Low weight and maximum compactness also ensure easy transportability to all intervention sites, both indoors and outdoors.
Characteristics:
- Polarity change for GAS MIG-MAG/BRAZING welding;
- 27 synergic curves pre-set;
- LCD display of voltage, current, welding speed;
- Adjustments: wire ramp, electronic reactance, final wire burn-back time, post gas;
- 2/4-stroke operation selection, spot;
- VRD device;
- Thermostatic, overvoltage, undervoltage, overcurrent, motor generator protection (+/- 15%).
Complete with MIG-MAG torch, cable and earth clamp.
MMA TIG DC LIFT
MIG-MAG FLUX
1 PH 230V
15 kg REEL
CE MARKING
EAC CERTIFICATION

CABLE 124887
MT15 MIG TORCH 3M (RED) 742180
TOLEDO 250 GROUND CLAMP 250A 712030

CODE 816057
POWER FACTOR (cosphi) 0.7
SINGLE-PHASE MAINS VOLTAGE 230 V
D. ELECTRODES USABLE IN DC 1.6 - 3.2 mm
MAINS FREQUENCY 50 / 60 Hz
D. STEEL WELDING WIRE 0.6 - 1 mm
CURRENT REGULATION RANGE 20 - 220 A
D. STAINLESS STEEL WELDING WIRE 0.8 - 1 mm
MAX DC CURRENT (EN 60974-1) 180 @ 20% A
D. ALUMINUM WELDING WIRE 0.8 - 1 mm
DC CURRENT 100 A
D. 0.8 - 1.2 mm COOLED WELDING WIRE
MAX NO LOAD VOLTAGE 78 V
D. BRAZING WIRE 0.8 - 1 mm
MAXIMUM ABSORBED CURRENT 32 A
DIMENSIONS 79.5 x 37.5 x 73 cm
CURRENT ABSORBED AT 60% - MAX 15 A
WEIGHT 29.6 kg
MAX ABSORBED POWER 5 kW
EAN CODE 8056151817501
POWER CONSUMPTION AT 60% 2.2 kW
YIELD 84%
