SUPERIOR 630 CE VRD 230-400V MMA INVERTER 3PH WELDER TELWIN

SUPERIOR 630 CE VRD 230-400V WELDER

Shipping cost: Gratis for
3822,58 €
Tax included

3.133,26 € Tax excluded

Quantity
Available product, order it now.


SUPERIOR 630 CE VRD 230-400V
code 816032
Multi-process inverter welding machine with MMA and TIG-LIFT electrodes in direct current (DC) with microprocessor control, designed for welding cellulose electrodes and coated electrodes of aluminium, rutile, basic, stainless steel, cast iron type up to a diameter of 8 mm.
Superior 630 CE VRD includes the "gouging" functionality and makes MIG-MAG/FLUX welding possible with optional wire feeder.
Characteristics:
- reduced weight and size
- high stability of the welding current in the event of variations in the supply voltage
- instant control of welding droplet transfer
- arc force and hot start adjustment depending on the type of electrode in use
- anti-stick device
- VRD device
- storage on internal E2PROM of the last 9 alarms
- remote control ready
- thermostatic, overvoltage, undervoltage, overcurrent, motor generator protection (+/- 15%).
MMA TIG DC LIFT
CE MARKING
3 PH 230V-400V
EAC CERTIFICATION
TIG, DC, LIFT
TÜV CERTIFICATION
REMOTE CONTROLS

CODE 816032
MINIMUM POWER OF MOTOR GENERATOR 22 / 32 kW
THREE-PHASE MAINS VOLTAGE 230 / 400 V
YIELD 86%
MAINS FREQUENCY 50 / 60 Hz
POWER FACTOR (cosphi) 0.9 CURRENT REGULATORY RANGE 10 - 450 / 10 - 600 A
D. ELECTRODES USABLE IN DC 1.6 - 8 mm
MAX DC CURRENT (EN 60974-1)400 @ 35% / 500 @ 40% A
PROTECTION DEGREE IP23
DC CURRENT 300 / 400 A
DIMENSIONS 67 x 31 x 56 cm
MAX NO LOAD VOLTAGE 65 / 73 V
WEIGHT 43 kg
MAXIMUM ABSORBED CURRENT 44 / 35 A
EAN CODE 800489791864 8
CURRENT ABSORBED AT 60% - MAX 25 / 20 A
PIECES / PALLET 6 pcs/pallet
MAX ABSORBED POWER 16 / 23 kW
PIECES / PALLET - B3 pieces/pallet B
POWER CONSUMPTION AT 60% 10 / 13 kW
A leading Italian company in welding, plasma cutting and charging and starting systems. Professional solutions for workshops, body shops, construction sites and industry, featuring reliable, high-performance technologies.

TELWIN: ITALIAN WELDING TECHNOLOGY SINCE 1963

Telwin is a long-established Italian brand, specialising in inverter welders, plasma cutters and charging/starting systems for the professional sector. Its solutions are designed for high-intensity environments such as mechanical workshops, automotive workshops, body shops, construction sites and industrial maintenance, where precision and operational continuity are essential.

The range includes MIG/MAG, TIG, MMA, high-precision plasma cutting, smart battery chargers, digital starters and multifunction stations for body shops.

The various product lines are distinguished by power, duty cycle, inverter technology, portability and electronic protection systems, making them suitable for both fixed workstations and mobile applications.

Telwin is recognised for structural reliability, arc stability, certified safety and continuous innovation, supported by in-house research and technological development.

Professionals choose Telwin for consistent performance, weld bead quality, reduced processing times and operational continuity even under demanding conditions.
