813/8/S HOSE REELS SILVER ZECA SERIES 813 FOR AIR AND WATER 12 BAR Dinamitek 1
  • 813/8/S HOSE REELS SILVER ZECA SERIES 813 FOR AIR AND WATER 12 BAR Dinamitek 1
  • 813/8/S HOSE REELS SILVER ZECA SERIES 813 FOR AIR AND WATER 12 BAR Dinamitek 2
  • 813/8/S HOSE REELS SILVER ZECA SERIES 813 FOR AIR AND WATER 12 BAR Dinamitek 3

813/8/S HOSE REELS SILVER SERIES 813 FOR AIR AND WATER 12 BAR ZECA PIPE M 12 - DIAM INT PIPE 8 MM

HOSE REEL SERIES 813 STRUCTURE: ALUMINIUM SILVER

the tube in the dual-material PVC/PU, matte blue, double layer, with reinforcement in high tenacity polyester
internal diameter of 8 mm 5/16”
length 12 m

Shipping cost: Free for
306,67 €
Tax included

251,37 € Tax excluded

Quantity
Available product, order it now.

813/8/S HOSE reels SILVER SERIES 813 FOR AIR AND WATER 12 BAR ZECA PIPE m 12 - DIAM INT PIPE 8 mm
Hose reel high-performance with the case in die-cast aluminium, epoxy powder coated and metal bracket.
The fixing bracket is adjustable.
This hose reel is equipped with a mechanism designed to automatically stop the leakage of the pipe to secure it to the desired length and allow the user to work comfortable. This automatic Device to stop tube may be disconnected, if so required by the exigencies of the service.
Data sheet
Fluids
Air
Water

Tube
type bimaterial PVC/PU, matte blue
internal diameter of 8 mm 5/16”
tube length 12 m
piece of input 2 m
Hose reel
maximum pressure 12 bar
temperature - 5° C / + 40° C
size 400x370x190 mm
weight: 10,5 Kg

Fittings
connector 1/4” M BSP
fitting inlet 1/4” M
ISO EN 12100 EC 2006/42/EC are not suitable for food
TUV NORD certification Zertifizierung Baumusters geprüft
Model silver, also available in yellow
813/8 HOSE reel SERIES 813 FOR AIR AND WATER 12 BAR ZECA PIPE m 12 - DIAM INT PIPE 8 mm
Leading Italian company in the automotive and industrial sectors, specialising in cable reels and professional equipment for mechanical workshops

ZECA: ITALIAN EXCELLENCE FOR PROFESSIONALS SINCE 1929

Zeca is a historic brand specializing in cable reels, hose reels, professional lamps and work organization tools.

Its solutions are designed for high-intensity environments such as workshops, automotive, construction, agriculture, and industry.

The product range includes electric and signal transmission cable reels, hose reels for air and fluids, rechargeable and under-hood lamps, balancers, and garage tools.

The different lines differ in terms of materials, capacity, cable length and degree of protection, so that they can be adapted to fixed or mobile locations.

Zeca is well-known for its products' durability, certified safety (ISO 9001, 14001, 45001) and continuous innovation, backed by patents and rigorous internal testing.

Professionals choose Zeca for mechanical reliability and practicality even in harsh conditions.



813/8/S

SERIES 813 ZECA

Download (663.39k)
